CRANKSHAFT/PISTON/ROTARY VALVE (

F7A 1972 USA

Crankshaft/piston/rotary valve ( Schemat F7A 1972 USA

CRANKSHAFT/PISTON/ROTARY VALVE ( F7A 1972 USA

ceny są w EUR

Ref

Część #

opis

Ilość

1

13008027
Ref: 1

RING-SET-PISTON,STD

€ 65.50

2

92036003
Ref: 2

CIRCLIP-PISTON PIN

€ 0.50

3

13001042
Ref: 3

PISTON,STD

€ 48.00

4

13002018
Ref: 4

PIN-PISTON

€ 21.00

5

13033034
Ref: 5

BEARING-NEEDLE,R1422P

€ 27.50

?

13044039
Ref: ?
Includes items 6 - 9

CONNECTING ROD SET

€ 177.00

?

13036049
Ref: ?
Includes items 6 - 1

CRANK & CONROD ASSY

€ 503.00

7

92026011
Ref: 7

SPACER,22.5X37X1.0

€ 6.00

8

13035022
Ref: 8

CRANK PIN

€ 16.50

9

13034042
Ref: 9

BEARING-NEEDLE,22VS29

€ 17.00

10

13037038
Ref: 10

CRANKSHAFT,L.H

€ 95.50

12

13038034
Ref: 12

CRANKSHAFT,R.H

€ 273.00

13

92038003
Ref: 13

WOODRUFF KEY-PRY PINI

€ 1.00

14

92027118
Ref: 14

COLLAR-CRANKSHAFT

€ 2.50

15

92027100
Ref: 15

COLLAR-R.H CRNK SHFT

€ 35.00

16

92055018
Ref: 16

RING-O,22MM

€ 2.50

17

13121027
Ref: 17

PINION,PRIMARY

€ 58.50

18

92024067
Ref: 18

WASHER,LOCK

€ 2.00

19

92015019
Ref: 19

NUT,18MM

€ 4.00

20

610A0412
Ref: 20

ROLLER,4X12

€ 2.50

21

12002022
Ref: 21

VALVE-ROTARY DISC

€ 60.50

22

92038001
Ref: 22

WOODRUFF KEY

€ 3.00

23

92022172
Ref: 23

WASHER,14.5X25X3.6

€ 6.00

24

461E1400
Ref: 24

WASHER-SPRING,14MM

€ 0.50

25

92015043
Ref: 25

NUT,14MM

€ 3.50
