031 SWINGARM AND CHAIN

Ref

Część #

opis

Ilość

1

74810231A
Ref: 1

NUT

€ 8.50

2

81910392A
Ref: 2

REAR WHEEL SPINDLE

€ 0.00

3

77911192A
Ref: 3

SCREW M6X20

€ 1.00

4

44710331A
Ref: 4

LOWER CHAIN SLIDING SHOE

€ 34.50

5

43312651A
Ref: 5

STICKER, ADJUSTING CHAIN

€ 5.50

5

43312651B
Ref: 5
J

STICKER, ADJUSTING CHAIN

€ 3.50

6

87210191A
Ref: 6

PLUG

€ 1.00

7

88440071A
Ref: 7

SPRING RING

€ 1.00

8

36910041A
Ref: 8

AXLE, REAR SWING ARM

€ 98.50

9

60N102556
Ref: 9

SCREW M8X25

€ 2.00

10

37010281A
Ref: 10

SWING ARM

€ 1,744.50

11

67620371A
Ref: 11

FINAL DRIVE KIT

€ 230.50

12

85210011A
Ref: 12

THRUST WASHER 1.8 MM

€ 2.00

12

85210021A
Ref: 12

THRUST WASHER 0.2 MM

€ 1.00

12

85210031A
Ref: 12

THRUST WASHER 0.1 MM

€ 1.00

13

44710341A
Ref: 13

UPPER CHAIN SLIDING SHOE

€ 34.50

14

036499710
Ref: 14

GASKET NYLON

€ 1.00

15

67640291A
Ref: 15

CHAIN

€ 166.50

16

56510251A
Ref: 16

REAR MUDGUARD

€ 225.50

17

37410021B
Ref: 17

PLATE CHAIN TIGHTENER

€ 9.00

18

77150042B
Ref: 18

SCREW M3X8

€ 1.00

19

85210791A
Ref: 19

WASHER 3.2X8X1.5

€ 1.00

20

37310011B
Ref: 20

SLIDING SHOE

€ 53.50

21

37310021A
Ref: 21

RIGHT COVER

€ 23.00

22

77910371A
Ref: 22

SCREW

€ 17.00

23

37310041A
Ref: 23

LEFT COVER

€ 32.50

24

60N102557
Ref: 24

SCREW TCEI M8X1.25X30

€ 1.00

25

80820022A
Ref: 25

PIN

€ 22.00

26

82111131A
Ref: 26

LOCATING PIN

€ 21.50

27

87210311A
Ref: 27

PLUG

€ 1.00
