006 HALF CRANKCASES

Ref

Część #

opis

Ilość

1

22520411A
Ref: 1

CRANKCASE

€ 1,079.00

2

075549265
Ref: 2

OIL SEAL

€ 3.00

3

764000004
Ref: 3

BEARING, NEEDLE

€ 7.50

4

762662668
Ref: 4

SPRING RING

€ 1.00

5

942470014
Ref: 5

LIQUID GASKET

€ 16.50

6

76610141A
Ref: 6

STUD BOLT FASTENING HEAD CYLINDER

€ 22.50

7

85610251A
Ref: 7

WASHER, SPECIAL

€ 1.00

8

067092010
Ref: 8

NUT, FLANGED M10

€ 2.00

9

757911747
Ref: 9

ROLLERS BEARING NJ203ECP

€ 66.50

10

720941616
Ref: 10

SCREW TSPEI M6X12

€ 1.00

11

82610031A
Ref: 11

PLATE, RETAINER

€ 13.50

12

70250191A
Ref: 12

BEARING 25X62X17

€ 25.50

13

937832552
Ref: 13

OIL SEAL

€ 7.50

14

71311401A
Ref: 14

SPACER

€ 2.00

15

60N101079
Ref: 15

SCREW TE M6X1.00X16

€ 1.00

16

937851830
Ref: 16

OIL SEAL

€ 9.50

17

757941542
Ref: 17

BEARING

€ 31.50

18

735033380
Ref: 18

CIRCLIP

€ 1.00

19

77150722B
Ref: 19

SCREW

€ 1.00

20

70250081A
Ref: 20

BALL BEARING 6003 TN9 C3

€ 10.50

21

71010701A
Ref: 21

BUSHING

€ 60.50

22

037049250
Ref: 22

WASHER

€ 1.00

23

001152010
Ref: 23

PIN DOWEL

€ 1.00

24

77151362B
Ref: 24

SCREW

€ 1.00

25

938233156
Ref: 25

O RING 39.34X2.62

€ 3.00

26

77910291A
Ref: 26

SCREW, SPECIAL

€ 11.50

27

71010691A
Ref: 27

BUSHING

€ 122.50

28

42020062A
Ref: 28

ALUMINIUM GASKET

€ 1.00

29

77911821A
Ref: 29

SPECIAL SCREW M12X1

€ 20.00

30

59310031B
Ref: 30

VALVE, BREATHER

€ 71.00

31

77150802B
Ref: 31

SCREW M6X75

€ 1.00

32

751433380
Ref: 32

BALL BEARING 35BN03D06

€ 92.00

33

751913380
Ref: 33

BEARING

€ 85.00

34

71110951A
Ref: 34

PIN DOWEL

€ 3.00
