007 CYLINDERS - PISTONS

SBK749S 2004 USA (SUPERBIKE 749S) 9151-2062A

007 cylinders - pistons technisch schema SBK749S 2004 USA (SUPERBIKE 749S) 9151-2062A

prijzen zijn in EUR

ref

onderdeelnr

omschrijving

hoeveelheid

12221151A
ref: 1

PISTON ASSY

€ 410.50

12110791A
ref: 2

CIRCLIP, PISTON PIN

€ 5.50

12111571A
ref: 3

PISTON PIN

€ 32.50

12120361A
ref: 4

PISTON RING SET 90 MM

€ 122.00

77150658B
ref: 5

SCREW TCEI M6X16

€ 1.00

79120351A
ref: 6

GASKET SET

€ 253.50

88650111A
ref: 7

O-RING

€ 2.00

24711201A
ref: 8

COVER, TIMING BELT INSIDE

€ 291.00

24711551A
ref: 9

COVER

€ 62.50

12020971A
ref: 10

CYLINDER ASSY

€ 1,122.50

78610702A
ref: 11

GASKET, CYLINDER HEAD

€ 73.50

71110932A
ref: 12

PIN DOWEL

€ 2.00

78610561A
ref: 13

GASKET,CYLNDER BASE 0.4 MM

€ 8.00

81410811A
ref: 14

CYLINDER WATER INTAKE CONNECTOR

€ 24.50

74140021A
ref: 15

CLAMP

€ 2.00

80011231A
ref: 16

HORIZONTAL CYLINDER WATER INLET HOSE

€ 24.50

80011221A
ref: 17

VERTICAL CYLINDER WATER INLET HOSE

€ 24.50
