REAR HUB/BRAKE/CHAIN ('81-'82 A2

Ref

Część #

opis

Ilość

41034

410341017
Ref: 41034

DRUM ASSY,REAR

€ 327.00

41035

410351071
Ref: 41035

PANEL-ASSY-BRAKE,RR

€ 263.50

41048

410481016
Ref: 41048

SHOE-BRAKE (MCA)

€ 25.00

41050

410501017
Ref: 41050

CAM SHAFT,RR BRAKE

€ 14.50

41053

410531019
Ref: 41053

LEVER,FR BRAKE CAM

€ 27.50

41068

410681043
Ref: 41068

AXLE,REAR

€ 38.00

42036

420361009
Ref: 42036

SLEEVE,RR BRAKE PANEL

€ 39.50

42036A

420361035
Ref: 42036A

SLEEVE,RR PANEL,RH

€ 46.00

42041

420411038
Ref: 42041
(OPTION)

REAR,SPROCKET,48T

€ 66.50

42041A

420411043
Ref: 42041A
(OPTION)

REAR SPROCKET,50T

€ 43.00

42041B

420411044
Ref: 42041B

REAR SPROCKET,52T

€ 99.50

92001

920011040
Ref: 92001

BOLT,HEX HEAD,8X32

€ 5.50

92015

920151013
Ref: 92015

NUT,LOCK,16MM

€ 32.50

92015A

920151078
Ref: 92015A

NUT,6M/M

€ 1.50

92015B

920151134
Ref: 92015B

NUT,8MM

€ 3.50

92027

920271040
Ref: 92027

COLLAR,L=11.5

€ 11.50

92027A

920271206
Ref: 92027A

COLLAR,REAR AXLE

€ 29.50

92027B

920271207
Ref: 92027B

COLLAR,REAR DRUM

€ 24.00

92045

601B6003U
Ref: 92045

BEARING-BALL,#6003UC3

€ 20.00

92046

920461009
Ref: 92046

BEARING-NEEDLE,HK1216

€ 13.50

92057

920571051
Ref: 92057

CHAIN ASSY,DRIVE,118L

€ 36.50

92058

920581051
Ref: 92058

JOINT-CHAIN

€ 5.50

92081

920811766
Ref: 92081

SPRING,BRAKE SHOE

€ 5.00

92081A

920811550
Ref: 92081A

SPRING,BRAKE SHOE

€ 5.50

92093

920931004
Ref: 92093

OIL SEAL

€ 3.50

110

112G0630
Ref: 110

BOLT-UPSET

€ 1.00

114

115G0835
Ref: 114

BOLT HEX,HEAD,8X35

€ 2.50

481

481J3500
Ref: 481

CIRCLIP-TYPE-C,35MM

€ 1.00

601

601B6004UU
Ref: 601

BEARING-BALL,#6004UUC

€ 25.00

670

670B2011
Ref: 670

O RING,11MM

€ 1.00

670A

670B2012
Ref: 670A

O RING,12MM

€ 1.00
