28A - SWING ARM - XDIAVEL 2017 (XDIAVEL) D240-00017

Ref

Część #

opis

Ilość

1

36911391A
Ref: 1

AXLE, REAR SWING ARM

€ 127.50

2

71140021A
Ref: 2

BUSH WITH COLLAR

€ 3.00

3

87311563AA
Ref: 3

PLUG

€ 12.00

4

80810461A
Ref: 4

CLAMP

€ 6.00

5

74840341B
Ref: 5

NUT M8

€ 1.00

6

70140491A
Ref: 6

BEARING, NEEDLE

€ 13.50

7

93041271A
Ref: 7

SEAL RING 20X26X4

€ 3.00

8

85210011B
Ref: 8

THRUST WASHER 20.5X36X1.8 MM

€ 2.00

8

85210021B
Ref: 8

THRUST WASHER 20.5X36X0.2 MM

€ 1.00

8

85210031B
Ref: 8

THRUST WASHER 20.5X36X0.1 MM

€ 1.00

9

87211151A
Ref: 9

PLUG

€ 2.00

10

87210741A
Ref: 10

CAP, SWINGARM COVER

€ 3.00

11

37011923AC
Ref: 11

REAR SWINGING ARM

€ 1,733.50

12

87211111A
Ref: 12

PLUG

€ 3.00

13

77211091D
Ref: 13

SCREW

€ 5.50

14

7715124BF
Ref: 14

SCREW

€ 2.00

15

37513421AC
Ref: 15

FORK

€ 54.00

16

4601D682A
Ref: 16

GUARD

€ 20.00

17

77210852C
Ref: 17

SCREW

€ 1.00

18

77150638B
Ref: 18

SCREW TCEI M6X12

€ 1.00

19

74140621A
Ref: 19

HOSE CLAMP 8 MM

€ 5.50

20

77918251AA
Ref: 20

SCREW, SPECIAL

€ 14.00

21

87240561A
Ref: 21

PLUG

€ 1.00

22

83210031E
Ref: 22

PIN

€ 4.00

23

7715121BF
Ref: 23

SCREW M8X16

€ 2.00

24

56510842A
Ref: 24

REAR MUDGUARD

€ 45.00

25

77210853B
Ref: 25

SCREW

€ 3.00

26

44610341A
Ref: 26

VERTICAL TIMING BELT COVER

€ 13.50

27

77210861B
Ref: 27

SCREW TBEI M5X18

€ 2.00

28

85041711A
Ref: 28

HOSE GUIDE

€ 1.00

29

77550221A
Ref: 29

SCREW TBEI M4X10

€ 1.00
