06 RADIATOR & HOSE

ref

onderdeelnr

omschrijving

hoeveelheid

1

5YP1241100
ref: 1

THERMOSTAT

€ 39.00

2

22BE241300
ref: 2

COVER, THERMOSTAT

€ 34.50

3

9010506X33
ref: 3

BOLT, FLANGE

€ 1.50

4

22BE240A10
ref: 4

RADIATOR ASSY

€ 372.00

5

22BE246110
ref: 5

RADIATEUR COMPLET

€ 208.50

6

5YPE240500
ref: 6

BLOWER ASSY

€ 165.00

7

5YPE267500
ref: 7

BOLT, BLOWER HOLDI

€ 1.50

8

5YPE267100
ref: 8

NUT 1

€ 1.50

9

3D71246200
ref: 9

CAP, RADIATOR

€ 22.00

10

9131703006
ref: 10

BOLT, SOCKET

€ 1.00

11

9048018276
ref: 11

GROMMET (4L0)

€ 1.50

12

9700706020
ref: 12

BOLT(4MY)

€ 1.00

13

9290706600
ref: 13

WASHER(6TA)

€ 1.00

14

90387068R3
ref: 14

COLLAR

€ 5.00

15

22BE257800
ref: 15

HOSE 3

€ 31.00

16

9045027X01
ref: 16

HOSE CLAMP ASSY

€ 4.00

17

22BE257900
ref: 17

HOSE 4

€ 17.50

18

9045027X01
ref: 18

HOSE CLAMP ASSY

€ 4.00

19

9044510X02
ref: 19

HOSE

€ 4.50

20

9046711090
ref: 20

CLIP (26H)

€ 2.50

21

9046711090
ref: 21

CLIP (26H)

€ 2.50

22

9046409M31
ref: 22

CLAMP(6M7)

€ 3.00

23

9046412X01
ref: 23

CLAMP

€ 4.00

24

9038708X09
ref: 24

ENTRETOISE

€ 14.00

25

9011106X17
ref: 25

BOLT HEX

€ 1.00

26

22BF172K10
ref: 26

BRACKET 1

€ 65.00

27

9018306X00
ref: 27

NUT, SPRING

€ 4.00

28

22BF637G00
ref: 28

HOLDER WIRE

€ 16.50

29

9581708014
ref: 29

BOLT, FLANGE

€ 1.50

30

22BF187110
ref: 30

TANK RECOVERY

€ 65.50

31

9010906X05
ref: 31

BOLT

€ 4.50

32

5TG2187500
ref: 32

CAP

€ 11.00

33

22BF182600
ref: 33

PIPE BREATHER

€ 24.50

34

9046711090
ref: 34

CLIP (26H)

€ 2.50

35

22BF187700
ref: 35

PIPE OVERFLOW

€ 19.50

36

9046415065
ref: 36

CLAMP(53Y)

€ 7.50

37

9046711090
ref: 37

CLIP (26H)

€ 2.50

38

26H2182800
ref: 38

ELBOW

€ 8.50

39

90183060A6
ref: 39

NUT, SPRING

€ 3.00
