FUEL COCK

GR650X 1983 (D) (E01 E02 E06 E22 E24 E39)

Fuel cock スキーマ GR650X 1983 (D) (E01 E02 E06 E22 E24 E39)

FUEL COCK GR650X 1983 (D) (E01 E02 E06 E22 E24 E39)
FUEL COCK GR650X 1983 (D) (E01 E02 E06 E22 E24 E39)
価格は EUR 単位です
参照
パーツ番号
説明
量
1-1
4430034470
参照: 1-1
MODEL D
COCK ASSEMBLY,FUEL
€ 95.00
1-2
4430015570
参照: 1-2
MODEL E
COCK ASSEMBLY,FUEL
€ 95.00
2
4434849170
参照: 2
O RING
4434849170
€ 3.50
3
0912806006
参照: 3
BOLT(6X20)
0912806006
€ 1.50
4
0916806010
参照: 4
GASKET
0916806010
€ 1.50
5
0934307073
参照: 5
HOSE
0934307073
€ 15.50
6
0940110403
参照: 6
CLIP
0940110403
€ 2.00
7
0944013020
参照: 7
SPRING
€ 9.00
8
3481015501
参照: 8
GAUGE ASSEMBLY,FUEL LEVEL
€ 78.50
9
3482545100
参照: 9
GASKET,FUEL LEVEL GAUGE (NAS)
3482545100
€ 6.00
10
0211205108
参照: 10
SCREW
0211205108
€ 1.50
11
0832121056
参照: 11
LOCK WASHER
0832121056
€ 2.50
12
0110705108
参照: 12
BOLT 5X10
0110705108
€ 1.50
13
0832121056
参照: 13
LOCK WASHER
0832121056
€ 2.50
14
3488534500
参照: 14
PLATE,FUEL DRAIN
3488534500
€ 19.50
15
3488834500
参照: 15
GASKET (NAS)
3488834500
€ 8.00
16
0211205086
参照: 16
SCREW
€ 1.50
17
0832121056
参照: 17
LOCK WASHER
0832121056
€ 2.50
18
0934305165
参照: 18
HOSE,FUEL
0934305165
€ 12.00
19
0940108402
参照: 19
CLIP
0940108402
€ 1.50
