010A HALF CRANKCASES

SBK998S 2002 EU (SUPERBIKE 998S BAYLISS) 9151-1531A

010a half crankcases diagramma SBK998S 2002 EU (SUPERBIKE 998S BAYLISS) 9151-1531A

i prezzi sono in EUR

rif

parte #

descrizione

quantità

70250191A
rif: 1

BEARING 25X62X17

€ 25.50

70240231A
rif: 2

BEARING

€ 66.50

942470014
rif: 3

LIQUID GASKET

€ 16.50

71311401A
rif: 4

SPACER

€ 2.00

60N101079
rif: 5

SCREW TE M6X1.00X16

€ 1.00

78010051A
rif: 6

THREADED PLUG M14X1.5

€ 7.00

71110951A
rif: 7

PIN DOWEL

€ 3.00

937851830
rif: 8

OIL SEAL

€ 9.50

757941542
rif: 9

BEARING

€ 31.50

735033380
rif: 10

CIRCLIP

€ 1.00

751433380
rif: 11

BALL BEARING 35BN03D06

€ 92.00

71010631A
rif: 12

BUSHING

€ 114.00

41760829A
rif: 13

SCREW

€ 2.00

77150722B
rif: 14

SCREW

€ 1.00

77150802B
rif: 15

SCREW M6X75

€ 1.00

77910291A
rif: 16

SCREW, SPECIAL

€ 11.50

77151362B
rif: 17

SCREW

€ 1.00
