004 CLUTCH

SBK998S 2002 EU (SUPERBIKE 998S BAYLISS) 9151-1531A

004 clutch diagramma SBK998S 2002 EU (SUPERBIKE 998S BAYLISS) 9151-1531A

004 CLUTCH SBK998S 2002 EU (SUPERBIKE 998S BAYLISS) 9151-1531A
004 CLUTCH SBK998S 2002 EU (SUPERBIKE 998S BAYLISS) 9151-1531A
i prezzi sono in EUR
rif
parte #
descrizione
quantità
1
065916555
rif: 1
CLUTCH SPRING
065916555
€ 3.00
2
84110022A
rif: 2
RETAINER
84110022A
€ 5.50
3
81820091A
rif: 3
PUSH ROD
81820091A
€ 13.50
4
77150432B
rif: 4
SCREW M5X20
77150432B
€ 1.00
5
85140011A
rif: 5
WASHER, LOCK
85140011A
€ 3.00
6
76410031B
rif: 6
WHEEL RUNNER BUSH
€ 5.50
7
16210011B
rif: 7
BOSS, CLUTCH
16210011B
€ 82.50
8
19020042A
rif: 8
CLUTCH DISC SET
€ 332.00
9
85110011B
rif: 9
WASHER
85110011B
€ 4.50
10
19610011B
rif: 10
CLUTCH DRUM
19610011B
€ 108.50
11
706108120
rif: 11
SCREW M8X20
706108120
€ 1.00
12
19420012A
rif: 12
DISK, CLUTCH PRESSURE
€ 86.50
13
19810032C
rif: 13
CLUTCH HOUSING
€ 243.50
14
70250161A
rif: 14
BEARING
70250161A
€ 13.50
15
46320537A
rif: 15
O-RING
46320537A
€ 1.00
16
46340269A
rif: 16
OIL SEAL 35-47-7
€ 11.50
17
17020321A
rif: 17
PRIMARY DRIVEN GEAR COMP.
€ 541.50
18
70240171A
rif: 18
BEARING 25X30X17
70240171A
€ 14.50
19
88120011A
rif: 19
CIRCLIP
€ 13.00
20
751132566
rif: 20
BALL BEARING 6005
€ 13.50
21
066016145
rif: 21
SPACER 25.2X33.7X2.8
€ 5.50
22
19540031A
rif: 22
CYLINDER, CLUTCH PRESSURE
19540031A
€ 93.00
23
71010021A
rif: 23
SPINDLE, TAPER
71010021A
€ 33.00
24
742240570
rif: 24
PIN 2.5X10 SW
742240570
€ 1.00
25
75010021B
rif: 25
NUT
75010021B
€ 16.00
26
040017030
rif: 26
O RING 2031
040017030
€ 1.00
27
88640431A
rif: 27
O-RING
88640431A
€ 1.00
28
60N107335
rif: 28
SCREW TCEI M6X1.00X16
€ 1.00
29
11720061A
rif: 29
ROD-PUSH, CLUTCH
€ 36.50
30
938232018
rif: 30
O-RING
938232018
€ 1.00
31
71310121B
rif: 31
SPACER
€ 25.50
32
938230128
rif: 32
O-RING
938230128
€ 1.00
