REAR WHEEL

ref

pièce #

description

quantité

1

40545KF0000
ref: 1

ADJUSTER,L.CHAIN

€ 21.00

1

40545MY6670
ref: 1

ADJUSTER,CHAIN,L

€ 21.00

2

41201MG2670
ref: 2

SPR FINAL DRIVEN

€ 69.00

3

41231MC4000
ref: 3

RETAINER,RR.WHEEL

€ 19.00

4

41241MC4000
ref: 4

RUB,RR.WHEEL DAMP

€ 8.00

4

41241MC4010
ref: 4

RUBBER,RR.WHEEL D

€ 8.00

5

42312MC4000
ref: 5

COLLAR,RR.WHEEL

€ 18.50

6

426A0MG2000
ref: 6

SPOK SET,B9X160.5

€ 3.50

7

426B0MG2000
ref: 7

SPOK SET,B9X153.5

€ 3.50

8

426C0MG2000
ref: 8

SPOKESET B9X157.5

€ 3.00

9

42601MG2000
ref: 9

HUB RR.WHEEL

€ 517.50

10

42611MG2000
ref: 10

FLANG FINAL DRIVE

€ 174.50

11

42620KAZ000
ref: 11

COLLAR,RR.AXLE DI

€ 15.00

11

42620MG2000
ref: 11

COLLAR,A,RR,AXL,D

€ 15.00

11

42620MK5680
ref: 11

COLLAR A,RR.AXLE

€ 15.00

12

42625MC4000
ref: 12

COLLAR B,RR.DIST.

€ 13.50

13

42701MG2003
ref: 13

RIM,RR.WHEEL

€ 514.50

13

42701MG2013
ref: 13

RIM,RR.WHEEL

€ 514.50

14

42711MG2672
ref: 14

TIRE,RR.(DUNLOP)

€ 252.50

14

42711MG2673
ref: 14

TIRE,RR. (BS)

€ 252.50

15

0840037100
ref: 15

TUBE, TIRE (4.50-17)

€ 49.50

15

42712KB7902
ref: 15

TUBE,TIRE

€ 63.00

15

42712MA0003
ref: 15

TUBE, TIRE

€ 49.50

15

42712MA0005
ref: 15

TUBE,TIRE 5.10-17

€ 49.50

15

42712MN9003
ref: 15

TUBE,TIRE (120/90

€ 49.50

15

42712371003
ref: 15

TUBE 450-17A TR-6

€ 49.50

15

42712371004
ref: 15

TUBE,WHEEL

€ 49.50

16

42713MG7003
ref: 16

FLAP,TIRE

€ 5.00

16

42713425771
ref: 16

FLAP,TIRE

€ 12.50

16

42713425772
ref: 16

FLAP,TIRE

€ 12.50

17

42717329000
ref: 17

CAP,RIM HOLE

€ 6.50

18

44606283000
ref: 18

BALANCER,HEEL(20G

€ 7.00

19

90128MG2000
ref: 19

BOLT,SPRKT FIXING

€ 7.50

20

90305MA0003
ref: 20

NUT,AXLE,16MM

€ 4.50

21

90309KF0003
ref: 21

NUT,FLANGE 8MM

€ 4.50

21

90309428731
ref: 21

NUT,FLANGE,8MM

€ 4.50

22

90465MC4000
ref: 22

WASHER,8MM

€ 4.00

23

91252MC4003
ref: 23

OILSEAL,28X47.2X7

€ 16.00

23

91252MC4005
ref: 23

OIL,28X47.2X7

€ 16.00

23

91252MC4013
ref: 23

OIL SEAL 28X47.2X

€ 16.00

24

91302317700
ref: 24

O RING RETAINER

€ 5.00

24

91307MB0000
ref: 24

O-RING, 54X2

€ 3.00

24

91307MB0003
ref: 24

O-RING,54X2

€ 3.00

25

9411116000
ref: 25

SPG-WASHER 16MM

€ 1.00

26

9452047000
ref: 26

CIRCLIP IN 47MM

€ 3.50

27

961406203010
ref: 27

B/BRG RAD N/COM

€ 19.00

28

961406204010
ref: 28

B/BRG RAD N/COM

€ 22.50
