FRONT WHEEL

VL1500 BOULEVARD C90 2007 (K7) USA (E03)

Front wheel diagram VL1500 BOULEVARD C90 2007 (K7) USA (E03)

FRONT WHEEL VL1500 BOULEVARD C90 2007 (K7) USA (E03)
FRONT WHEEL VL1500 BOULEVARD C90 2007 (K7) USA (E03)
prices are in EUR
ref
part #
description
quantity
1
5411110F20YAA
ref: 1
WHEEL,FR(16XMT3.50)
5411110F20YAA
€ 945.00
1
5411110F20YAA
ref: 1
WHEEL,FR(16XMT3.50)
5411110F20YAA
€ 945.00
2
5473110F00
ref: 2
SPACER,FR HUB BEARING
5473110F00
€ 16.00
3
0813362037
ref: 3
BEARING
0813362037
€ 19.50
4
5471110F01
ref: 4
AXLE,FR
5471110F01
€ 105.50
5
5474010F00
ref: 5
SPACER,FR AXLE,R
5474010F00
€ 23.00
6
5474032C00
ref: 6
SPACER,FR AXLE,R
5474032C00
€ 11.50
7
5479238B00
ref: 7
CAP,FR AXLE
5479238B00
€ 80.00
8
5921110F10
ref: 8
DISC,FR BRAKE,R
5921110F10
€ 166.00
9
5922110F10
ref: 9
DISC,FR BRAKE,L
5922110F10
€ 157.50
10
0910608148
ref: 10
BOLT(8X33)
0910608148
€ 5.00
11-1
5511010F01
ref: 11-1
TIRE,FR(150/80-16 71H)
€ 619.50
11-1
5511010F01
ref: 11-1
TIRE,FR(150/80-16 71H)
€ 619.50
11-2
5511010F10
ref: 11-2
TIRE,FR
5511010F10
€ 206.50
11-2
5511010F10
ref: 11-2
TIRE,FR
5511010F10
€ 206.50
12
4313024A00
ref: 12
VALVE ASSY,WHEEL RIM(TR412)
4313024A00
€ 6.50
13-1
4322273H10
ref: 13-1
WEIGHT,WHEEL BALANCE 10G
4322273H10
€ 4.00
13-2
4322473H10
ref: 13-2
WEIGHT,WHEEL BALANCE 20G
4322473H10
€ 5.00
13-3
4322673H10
ref: 13-3
WEIGHT,WHEEL BALANCE 30G
€ 6.00
14
5479138B01
ref: 14
CAP,FR AXLE
5479138B01
€ 6.00
