004 CLUTCH

ref

part #

description

quantity

1

77150432B
ref: 1

SCREW M5X20

€ 1.00

2

84110241A
ref: 2

RETAINER

€ 7.00

3

81810101B
ref: 3

PIECE, CLUTCH PUSH

€ 28.50

4

065916558
ref: 4

CLUTCH SPRING

€ 3.00

5

19420031A
ref: 5

DISK, CLUTCH PRESSURE

€ 189.50

6

70250081A
ref: 6

BALL BEARING 6003 TN9 C3

€ 10.50

7

19020092B
ref: 7

CLUTCH DISC SET

€ 207.50

8

75010071A
ref: 8

NUT

€ 12.50

9

85110041A
ref: 9

WASHER, LOCK

€ 2.00

10

19610162A
ref: 10

BOSS, CLUTCH

€ 118.50

11

85610141A
ref: 11

WASHER, THRUST

€ 9.00

12

17020312A
ref: 12

PRIMARY DRIVEN GEAR COMP.

€ 639.00

13

88110261A
ref: 13

BEARING INNER RING

€ 30.50

14

70250151A
ref: 14

BEARING, NEEDLE

€ 46.00

15

71311191A
ref: 15

SPACER

€ 13.00

16

11720071A
ref: 16

CLUTCH CONTROL ROD

€ 32.50

17

88640431A
ref: 17

O-RING

€ 1.00

18

938232018
ref: 18

O-RING

€ 1.00

19

19540031A
ref: 19

CYLINDER, CLUTCH PRESSURE

€ 93.00

20

60N107335
ref: 20

SCREW TCEI M6X1.00X16

€ 1.00

all assemblies
