SIDE COVER

XVS1300A UBS 2016 1CS8 EUROPE 1R1CS-300E1

Side cover Schemat XVS1300A UBS 2016 1CS8 EUROPE 1R1CS-300E1

SIDE COVER XVS1300A UBS 2016 1CS8 EUROPE 1R1CS-300E1
SIDE COVER XVS1300A UBS 2016 1CS8 EUROPE 1R1CS-300E1
ceny są w EUR
Ref
Część #
opis
Ilość
1
3D82177G02
Ref: 1
BOX, BATTERY
€ 35.50
2
9038706267
Ref: 2
COLLAR
€ 2.00
3
9502206020
Ref: 3
BOLT, FLANGE
9502206020
€ 1.00
4
51Y8212200
Ref: 4
SEAT, BATTERY
€ 3.00
5
5PX2165200
Ref: 5
PROTECTOR
€ 11.50
6
3D82174Y00
Ref: 6
DAMPER
€ 1.00
7
3D82174X00
Ref: 7
DAMPER
€ 2.50
8
3D82177900
Ref: 8
DAMPER, LOCATING 2
€ 2.00
9
3D82177M00
Ref: 9
DAMPER, LOCATING 3
€ 4.50
10
3D82817310
Ref: 10
BOX, TOOL
€ 14.00
11
2GH2418500
Ref: 11
DAMPER
2GH2418500
€ 1.50
12
1AE2834E00
Ref: 12
DAMPER (L.H)
1AE2834E00
€ 1.50
13
3L88213101
Ref: 13
BAND, BATTERY
€ 7.00
14
3D82171100P0
Ref: 14
SMX
COVER, SIDE 1
€ 174.00
15
9038706173
Ref: 15
COLLAR
€ 4.00
16
9014906023
Ref: 16
SCREW
9014906023
€ 5.00
17
3D82175T00
Ref: 17
BRACKET 1
€ 43.00
18
9770250012
Ref: 18
SCREW, TAPPING(3NG)
€ 1.00
19
5PXW247000
Ref: 19
ROTOR SET
5PXW247000
€ 85.00
20
9020106034
Ref: 20
WASHER, PLATE
€ 2.50
21
9010506639
Ref: 21
BOLT, WASHER BASED(3XC)
€ 2.00
22
3D82172M10
Ref: 22
BRACKET 3
€ 57.00
23
9201206012
Ref: 23
HEX BOLT 6X12
€ 0.00
24
9048012550
Ref: 24
GROMMET(3VD)
9048012550
€ 2.50
25
3D82172100P0
Ref: 25
SMX
COVER, SIDE 2
€ 174.00
26
3MA2749100
Ref: 26
PROTECTOR
3MA2749100
€ 6.00
27
9038706173
Ref: 27
COLLAR
€ 4.00
28
9011106038
Ref: 28
BOLT
9011106038
€ 3.50
29
3D82172N00
Ref: 29
BRACKET 4
€ 66.00
30
9201206012
Ref: 30
HEX BOLT 6X12
€ 0.00
31
9048012550
Ref: 31
GROMMET(3VD)
9048012550
€ 2.50
32
9048018418
Ref: 32
GROMMET(46X)
€ 2.50
33
3D82174110
Ref: 33
COVER, SIDE 4
€ 178.50
34
31A2821700
Ref: 34
DAMPER 1
31A2821700
€ 7.00
35
9038706184
Ref: 35
COLLAR
€ 4.00
36
9011106038
Ref: 36
BOLT
9011106038
€ 3.50
37
9046415195
Ref: 37
CLAMP(4FM)
9046415195
€ 2.50
38
3D82176E10
Ref: 38
PLATE
3D82176E10
€ 40.50
39
9026907077
Ref: 39
RIVET(4PH)
9026907077
€ 1.50
40
3D82172K01
Ref: 40
BRACKET 1
€ 46.00
41
3D82177800
Ref: 41
DAMPER, LOCATING 1
€ 1.00
42
9201206012
Ref: 42
HEX BOLT 6X12
€ 0.00
43
3D82172L00
Ref: 43
BRACKET 2
€ 16.50
44
9201206012
Ref: 44
HEX BOLT 6X12
€ 0.00
45
9046417008
Ref: 45
CLAMP
€ 2.00
46
3D82187100
Ref: 46
TANK, RECOVERY
€ 41.50
47
9048013567
Ref: 47
GROMMET(4FU)
9048013567
€ 1.50
48
9011906137
Ref: 48
BOLT, WITH WASHER
9011906137
€ 1.00
49
3D82187500
Ref: 49
CAP
3D82187500
€ 12.50
50
9046711019
Ref: 50
CLIP, PIPE
€ 2.00
51
26H2182800
Ref: 51
ELBOW
26H2182800
€ 8.50
52
3D82182600
Ref: 52
PIPE, BREATHER
€ 11.00
53
9046708003
Ref: 53
CLIP 101235600
9046708003
€ 2.00
54
9044509097
Ref: 54
HOSE
€ 9.50
55
3D82810010
Ref: 55
TOOL KIT
€ 43.00
56
3D82811000
Ref: 56
TOOL KIT, 2
3D82811000
€ 36.00
57
1CS28199E2
Ref: 57
UR ENGLISH
O/M XVS1300A '16
€ 21.00
57
1CS28199F2
Ref: 57
UR FRENCH
O/M XVS1300A '16
€ 21.00
57
1CS28199G2
Ref: 57
UR GERMAN
O/M XVS1300A '16
€ 21.00
57
1CS28199H2
Ref: 57
UR PORTUGUESE
O/M XVS1300A '16
€ 21.00
57
1CS28199S2
Ref: 57
UR SPANISH
O/M XVS1300A '16
€ 21.00
58
3D81541E00
Ref: 58
STAY, COVER
€ 72.50
59
5EL1428300
Ref: 59
COVER, CARBURETOR 1
5EL1428300
€ 58.00
60
9011005057
Ref: 60
BOLT, HEXAGON SOCKET HEAD
9011005057
€ 1.50
61
27D2479600
Ref: 61
COVER
€ 10.00
