REAR WHEEL CL175

CL175 SCRAMBLER 1968 K0 USA

Rear wheel cl175 Schemat CL175 SCRAMBLER 1968 K0 USA

REAR WHEEL CL175 CL175 SCRAMBLER 1968 K0 USA
REAR WHEEL CL175 CL175 SCRAMBLER 1968 K0 USA
ceny są w EUR
Ref
Część #
opis
Ilość
0
06430354405
Ref: 0
SHOE SET,BRK (NAS)
06430354405
€ 46.50
1
40543216000
Ref: 1
ADJUSTER CHAIN
40543216000
€ 24.50
2
41201107670
Ref: 2
SPROCKET,DRIVEN
41201107670
€ 45.00
2
41201216840
Ref: 2
SPROCKET 40T
41201216840
€ 45.00
2
41201240000
Ref: 2
SPROCKET,DRIVEN
41201240000
€ 55.00
2
41201302010
Ref: 2
SPROCKET,DRIVEN
41201302010
€ 55.00
3
41241222000
Ref: 3
BUSH,REAR.DAMPER
41241222000
€ 14.50
3
41241307000
Ref: 3
BUSH,DAMPER,WHEEL
41241307000
€ 14.50
4
42301235000
Ref: 4
AXLE,REAR WHEEL
42301235000
€ 41.00
5
42311216000
Ref: 5
COLLAR WHEEL
42311216000
€ 33.00
6
42313216000
Ref: 6
COLLAR, PANEL
42313216000
€ 6.00
7
42601235000
Ref: 7
HUB, RR. WHEEL
42601235000
€ 398.50
8
42620235000
Ref: 8
COLLAR,REAR,AXLE
42620235000
€ 7.50
9
42701235000
Ref: 9
RIM, REAR WHEEL
42701235000
€ 103.50
9
42701235003
Ref: 9
RIM, REAR WHEEL
42701235003
€ 103.50
10
42711268000
Ref: 10
TIRE REAR 300X18
€ 48.50
10
42711307006
Ref: 10
TIRE (3.00-18) (4PR)
€ 48.50
11
0840021600
Ref: 11
TUBE, TIRE (2.75-18)
€ 38.00
11
42712166004
Ref: 11
TUBE,TIRE (DUNLOP
€ 38.00
11
42712216000
Ref: 11
TUBE, RR. (2.50-18)
€ 38.00
11
44712028000
Ref: 11
TUBE,WHEEL 250-18
44712028000
€ 38.00
11
44712150005
Ref: 11
TUBE,TIRE
44712150005
€ 38.00
11
44712205000
Ref: 11
TUBE, TIRE (2.75-18)
€ 38.00
11
44712268000
Ref: 11
TUBE 275X18
€ 38.00
11
44712268222
Ref: 11
TUBE, TIRE (2.50-18)
€ 38.00
11
44712315009
Ref: 11
TUBE,FRONT.WHEEL
€ 38.50
12
43100235000
Ref: 12
PANEL, RR. BRAKE
43100235000
€ 76.50
12
43100235010
Ref: 12
PANEL, RR. BRAKE
43100235010
€ 76.50
13
43141235000
Ref: 13
CAM REAR BRAKE
43141235000
€ 25.50
14
43410235010
Ref: 14
ARM,REAR BRAKE
€ 28.00
15
42713268003
Ref: 15
FLAP,X-18A
42713268003
€ 7.50
15
42713268810
Ref: 15
FLAP TIRE
€ 7.50
15
42713340006
Ref: 15
FLAP,18-25
€ 7.50
15
44713205000
Ref: 15
FLAP 18-20
€ 7.50
16
43120354670
Ref: 16
SHOE,RR.BRAKE (MCA)
43120354670
€ 46.50
16
45120240000
Ref: 16
SHOE,FRONT BRAKE (MCA)
45120240000
€ 46.50
16
45120240010
Ref: 16
SHOE,FRONT BRAKE (MCA)
45120240010
€ 46.50
17
45133240000
Ref: 17
SPRING,BRAKE SHOE
45133240000
€ 2.00
18
45134250000
Ref: 18
DUST-SEAL, BRAKE
45134250000
€ 2.00
19
90119258000
Ref: 19
BOLT,CHAIN ADJUST
90119258000
€ 5.50
20
90128216000
Ref: 20
BOLT,DRIVEN
90128216000
€ 8.00
21
90306235000
Ref: 21
NUT, RR. AXLE
90306235000
€ 4.50
22
90522222000
Ref: 22
WASHER 8.5X12MM
90522222000
€ 1.00
22
90523222000
Ref: 22
WASHER,TONGUED8MM
90523222000
€ 1.00
22
9410813000
Ref: 22
WASHER,TONGUED
9410813000
€ 1.00
23
90524030000
Ref: 23
WASHER, HANDLE
90524030000
€ 2.00
24
90664216000
Ref: 24
CIRCLIP, 58M/M
90664216000
€ 6.50
25
90757216000
Ref: 25
DUST SEAL WHEEL
90757216000
€ 4.50
25
90757216003
Ref: 25
DUST SEAL,DAMPER
90757216003
€ 4.50
26
9200006020
Ref: 26
BOLT,HEX 6X20
9200006020
€ 1.00
26
92101060200A
Ref: 26
BOLT,HEX.,6X20
92101060200A
€ 1.00
27
90310KA3711
Ref: 27
NUT HEX 6MM
€ 1.00
27
94000060000S
Ref: 27
NUT,HEX.,6MM
€ 1.00
27
9400106000
Ref: 27
NUT,HEX 6MM
9400106000
€ 1.00
27
94001060000S
Ref: 27
NUT,HEX 6MM
94001060000S
€ 1.00
27
94001060080S
Ref: 27
NUT,HEX.,6MM
€ 1.00
27
94001062000S
Ref: 27
NUT,HEX.,6MM
94001062000S
€ 1.00
27
9400208000
Ref: 27
NUT,HEX.,8MM
9400208000
€ 1.50
27
94002080000S
Ref: 27
NUT,HEX.,8MM
94002080000S
€ 1.00
27
9403006000
Ref: 27
NUT,HEX 6MM
€ 1.00
27
9403108000
Ref: 27
NUT,HEX.,8MM
9403108000
€ 1.50
28
90310KA3711
Ref: 28
NUT HEX 6MM
€ 1.00
28
94001060000S
Ref: 28
NUT,HEX 6MM
94001060000S
€ 1.00
28
94001060080S
Ref: 28
NUT,HEX.,6MM
€ 1.00
28
94001062000S
Ref: 28
NUT,HEX.,6MM
94001062000S
€ 1.00
28
9403006000
Ref: 28
NUT,HEX 6MM
€ 1.00
28
9403108000
Ref: 28
NUT,HEX.,8MM
9403108000
€ 1.50
29
9420120180
Ref: 29
PIN,SPLIT, 2.0
9420120180
€ 1.00
29
9420120200
Ref: 29
PIN COTTER 2.0MM
9420120200
€ 1.00
29
9420120220
Ref: 29
PIN,SPLIT, 2.0
9420120220
€ 1.00
29
9420120250
Ref: 29
PIN,SPLIT, 2.0
9420120250
€ 1.00
29
9420120280
Ref: 29
PIN,SPLIT, 2.0
9420120280
€ 1.00
29
9420120320
Ref: 29
PIN COTTER 2.0MM
€ 1.00
29
9420120350
Ref: 29
PIN COTTER 2.0MM
9420120350
€ 1.00
29
9420129220
Ref: 29
PIN SPLIT 2,0 X 22
€ 1.00
30
9452147000
Ref: 30
CIR CLIP,IN 47MM
9452147000
€ 2.00
30
9452447000
Ref: 30
CIRCLIP IN 47MM
9452447000
€ 2.00
31
9614063030
Ref: 31
B/BRG RAD N/COM
9614063030
€ 23.00
31
961406303000
Ref: 31
B/BRG RAD N/COM
€ 23.00
31
961406303010
Ref: 31
B/BRG RAD N/COM
961406303010
€ 23.00
32
97395521671
Ref: 32
SPOKE,9X163.5
97395521671
€ 4.50
32
973955216710
Ref: 32
SPOKE B, 9X163.5
973955216710
€ 4.50
33
97660521651
Ref: 33
SPOKE,9X162.5
97660521651
€ 1.50
