De online onderdelen catalogus

CA50J2 JAZZ JAPAN (11GS3GJ5)

technisch schema CA50J2 JAZZ JAPAN (11GS3GJ5)

CA50J2 JAZZ JAPAN (11GS3GJ5)
CA50J2 JAZZ JAPAN (11GS3GJ5)
prijzen zijn in EUR
ref
onderdeelnr
omschrijving
hoeveelheid
1
12191GB2004
ref: 1
GASKET,CYLINDER (NAS)
12191GB2004
€ 9.00
2
12209GB4681
ref: 2
SEAL,VLV STEM
12209GB4681
€ 6.00
2
12209GB4682
ref: 2
SEAL,VLV,STEM
12209GB4682
€ 6.00
3
12250GB2000
ref: 3
GSKT.CYLN.HEAD (NAS)
12250GB2000
€ 29.50
4
12391GB2003
ref: 4
GSKT,HEAD,COVER (NAS)
12391GB2003
€ 6.00
5
12394GB4680
ref: 5
GSKT,CYLN.HEAD R (NAS)
12394GB4680
€ 6.00
6
12395GB2003
ref: 6
GSKT,HEAD,COVER (NAS)
12395GB2003
€ 7.00
7
16201GS3003
ref: 7
GASKET,CARBURETOR
16201GS3003
€ 1.50
8
18291001010
ref: 8
GASKET,EX.PIPE (NAS)
18291001010
€ 3.50
9
91301GB0911
ref: 9
O-RING 14.5MM
91301GB0911
€ 6.00
10
91301GK4871
ref: 10
O-RING,27X2.0
91301GK4871
€ 3.00
11
91302001020
ref: 11
O RING, 30.8M/M
91302001020
€ 3.00
12
91303035000
ref: 12
PACKING,RUB.16M/M
91303035000
€ 4.00
13
91306141000
ref: 13
GASKET,RUBBER 9MM
91306141000
€ 3.00
14
061A1GS3010
ref: 14
GASKET KIT A (NAS)
€ 27.50
