HANDLEBAR (MODEL S)

VS1400GLP INTRUDER 1989 (K) USA (E03)

Handlebar (model s) diagramma VS1400GLP INTRUDER 1989 (K) USA (E03)

i prezzi sono in EUR

rif

parte #

descrizione

quantità

5611138B32
rif: 1

HANDLEBAR

€ 244.50

5650038B00
rif: 2
56500-38B01

MIRROR ASSEMBLY,REAR VIEW

€ 214.50

5660038B00
rif: 3
56600-38B01

MIRROR ASSEMBLY,REAR VIEW

€ 214.50

5830038B30
rif: 4

CABLE ASSY,THROTTLE

€ 83.00

0211275163
rif: 5
02112-7516A

SCREW

€ 2.00

5862138B00
rif: 6

CLAMP,THROTTLE CABLE CONNECTOR

€ 5.50

0211275163
rif: 7
02112-7516A

SCREW

€ 2.00

5840038B01
rif: 8
58400-39B00

CABLE ASSEMBLY,STARTER

€ 30.00

0214205087
rif: 9

SCREW

€ 2.00
