GENERATOR

EX500D3 NINJA 500 1996 USA CALIFORNIA CANADA

Generator diagramma EX500D3 NINJA 500 1996 USA CALIFORNIA CANADA

GENERATOR EX500D3 NINJA 500 1996 USA CALIFORNIA CANADA

i prezzi sono in EUR

rif

parte #

descrizione

quantità

120

120P0625
rif: 120

BOLT,6X25

€ 1.50

130

130B0625
rif: 130

BOLT,FLANGED,6X25

€ 0.50

220

220B0510
rif: 220

SCREW-PAN-CROS,5X10

€ 0.50

21003

210031123
rif: 21003

STATOR

€ 451.50

21050

210501162
rif: 21050

FLYWHEEL

€ 601.50

21066

210661030
rif: 21066

REGULATOR-VOLTAGE

€ 163.50

92002

920021457
rif: 92002

BOLT,FLANGED,10X36

€ 7.50

92037

920371630
rif: 92037

CLAMP,GENERATOR LEAD

€ 5.50
