035 OIL COOLER

MTS1100S 2007 USA (MULTISTRADA 1100 S) 9151-2512A

035 oil cooler diagramma MTS1100S 2007 USA (MULTISTRADA 1100 S) 9151-2512A

i prezzi sono in EUR

rif

parte #

descrizione

quantità

54840471A
rif: 1

OIL COOLER

€ 650.00

76410221A
rif: 2

VIBRATION DAMPER PAD

€ 2.00

71610031A
rif: 3

SPACER

€ 2.00

77250311B
rif: 4

SCREW TEF M6X20

€ 1.00

54910393A
rif: 5

PIPE

€ 123.50

54910383A
rif: 6

OIL DELIVERY PIPE

€ 106.50

81510221A
rif: 7

NIPPLE, HOSEM14X1.5

€ 9.00

78710111A
rif: 8

GASKET, ALUMINIUM 14X22X2

€ 1.00

71313651A
rif: 9

SPACER 6.2X10X3

€ 2.00

85250241A
rif: 10

WASHER 10X14X1

€ 1.00

55210452A
rif: 11

THERMISTOR

€ 50.50

75810211A
rif: 12

FAIRLEAD

€ 6.50

069191030
rif: 13

CLAMP

€ 1.00

77150728B
rif: 14

SCREW TCEI M6X35

€ 1.00

85211761A
rif: 15

WASHER 6.4X12.5X1.6

€ 1.00
