FRONT DAMPER

GSXR600 2009 (K9) USA (E03)

Front damper schéma GSXR600 2009 (K9) USA (E03)

FRONT DAMPER GSXR600 2009 (K9) USA (E03)
FRONT DAMPER GSXR600 2009 (K9) USA (E03)
les prix sont en EUR
ref
pièce #
description
quantité
1
5110301H10
ref: 1
DAMPER ASSY,FR FORK,R
€ 2,122.00
2
5110401H10
ref: 2
DAMPER ASSY,FR FORK,L
5110401H10
€ 2,122.00
3
5111001H10
ref: 3
TUBE,INNER,R
5111001H10
€ 765.50
4
5112001H10
ref: 4
TUBE,INNER,L
€ 857.00
5
5183001H10
ref: 5
PIECE,ADJUST
€ 62.00
6
5211001H10
ref: 6
DAMPER,FR
€ 687.50
7
5182101H00
ref: 7
PUSH ROD
5182101H00
€ 41.50
8
0928003002
ref: 8
O RING(D:1.9,ID:3.8)
0928003002
€ 2.00
9
0916110009
ref: 9
WASHER(10X15X1.5)
0916110009
€ 1.50
10
5114717C00
ref: 10
BOLT
5114717C00
€ 19.50
11
5116601H10
ref: 11
BOLT
5116601H10
€ 6.50
12
5117101H10
ref: 12
SPRING,FR
5117101H10
€ 126.00
13
5117601H10
ref: 13
COLLAR,SPRING
5117601H10
€ 12.50
14
5117522D00
ref: 14
GUIDE,SPRING UPR
5117522D00
€ 14.00
15
5113101H10
ref: 15
TUBE,OUTER
€ 671.00
16
5115201H10
ref: 16
BUSH,GUIDE
5115201H10
€ 13.50
17
5116801H00
ref: 17
SPACER,SEAL
€ 7.00
18
5115301H10
ref: 18
SEAL,OIL
5115301H10
€ 17.00
19
5155638B00
ref: 19
CIRCLIP,FORK OIL SEAL
5155638B00
€ 5.50
20
5117301H00
ref: 20
SEAL,DUST
5117301H00
€ 8.00
21
5118901H00
ref: 21
BOLT,FORK
5118901H00
€ 135.50
22
5118701H00
ref: 22
O RING,FORK BOLT
5118701H00
€ 5.00
