FRAME

ref

pièce #

description

quantité

32160

32160069418R
ref: 32160

FRAME-COMP,MAIN,F.S.B

€ 1,267.00

39156

391561811
ref: 39156

PAD,10X34X5

€ 2.00

92045

920451384
ref: 92045

BEARING-BALL,SF07A17P

€ 45.00

92049

920490022
ref: 92049

SEAL-OIL,DS35X55X4

€ 11.00

92066

920660071
ref: 92066

PLUG

€ 2.00

92153

921531442
ref: 92153

BOLT,SOCKET,10X35

€ 4.50

92154

921540379
ref: 92154

BOLT,SOCKET,8X23

€ 2.00

92200

922000036
ref: 92200

WASHER

€ 3.00

92210

922100095
ref: 92210

NUT,35MM

€ 12.50

32160A

32160069518R
ref: 32160A

FRAME-COMP,RR,LH,F.S.

€ 139.00

32160B

32160069618R
ref: 32160B

FRAME-COMP,RR,RH,F.S.

€ 139.00

32160C

321600697
ref: 32160C

FRAME-COMP,RR

€ 446.00

92049A

920490742
ref: 92049A

SEAL-OIL,43X55.5X8.6

€ 12.00

92154A

921542624
ref: 92154A

BOLT,TOP,26X18

€ 106.50

92200A

922000892
ref: 92200A

WASHER,27X48X2.3

€ 5.00

92210A

922100823
ref: 92210A

NUT,35MM

€ 16.50

toutes les assemblages
