FRONT FORK DAMPER (AN400AK9)

AN400 BURGMAN 2009 (K9) USA (E03)

Front fork damper (an400ak9) diagrama AN400 BURGMAN 2009 (K9) USA (E03)

FRONT FORK DAMPER (AN400AK9) AN400 BURGMAN 2009 (K9) USA (E03)

los precios están en EUR

ref

parte #

descripción

cantidad

1

5110305H60
ref: 1

DAMPER ASSY,FR FORK,R

€ 588.50

2

5110405H60
ref: 2

DAMPER ASSY,FR FORK,L

€ 588.50

3

5113005H60
ref: 3

TUBE,OUTER,R

€ 442.00

4

5114005H60
ref: 4

TUBE,OUTER,L

€ 442.00

5

5116726E10
ref: 5

METAL,SLIDE

€ 18.00

6

5115805A00
ref: 6

WASHER,FORK OIL SEAL

€ 4.50

7

5115310G50
ref: 7

SEAL,OIL

€ 12.00

8

5115649440
ref: 8

RING,OIL SEAL STOPPER

€ 4.00

9

5117314F00
ref: 9

SEAL,DUST

€ 14.50

10

5119533D10
ref: 10

PIECE,OIL LOCK

€ 16.00

11

5114705H00
ref: 11

BOLT

€ 3.50

12

5114841310
ref: 12

GASKET (NAS)

€ 1.50

13

5111005H00
ref: 13

TUBE,INNER

€ 227.00

14

5112133D10
ref: 14

PISTON

€ 13.50

15

5114605H00
ref: 15

CYLINDER

€ 66.00

16

5117714F70
ref: 16

SPRING,REBOUND

€ 8.00

17

5119614F51
ref: 17

RING,PISTON

€ 5.00

18

5117105H00
ref: 18

SPRING,FR

€ 51.00

19

5135627C00
ref: 19

WASHER,STEM HEAD(24.5X34X1.6)

€ 3.50

19

5135627C00
ref: 19

WASHER,STEM HEAD(24.5X34X1.6)

€ 3.50

20

5135114F20
ref: 20

CAP

€ 37.00

21

0928032001
ref: 21

O RING(D:3.5,ID:31.7)

€ 2.00

22

5132805H00
ref: 22

BOLT

€ 3.50
